Fitwel Industries LLP has been expanded our inventory and sales over the years through our sheer perseverance and innovation, giving us an edge over other producers. Our potential lies in fueling a businesses growth through complete assistance in product selection and application. Our WNR 1.4410 Super Duplex Steel Forged Socket Weld Elbows have a somewhat larger diameter than the connecting pipe to smoothly accommodate it besides having a low rate of thermal expansion suitable for nuclear energy development plants. Connecting pipe sections in the textile and refining industry, we are suppliers of ASME SA182 Super Duplex Steel UNS S37250 Forged Socket Weld Tees that defy crevice corrosion. Our ANSI B16.11 Super Duplex Steel Couplings handle high steam pressure effectively in gas pipelines. Our offered Super Duplex Steel UNS S32750 Forged Fittings, which gives fantastic protection from inorganic acids, particularly those containing chlorides. Super Duplex Forged Socket Weld Fittings consolidates the best traits of both austenitic and ferritic stainless steels. Forged Threaded Fittings gives high strength/malleability with great corrosion protection from erosion (including stress corossion breaking). Super Duplex Forged Fittings is intended to include high strength, protection from pitting, stress corrosion splitting, disintegration erosion and erosion weariness, crevice erosion and strong weldability. The high molybdenum and chromium content of Super Duplex UNS S32750 Forged Socket Weld Fittings makes it particularly impervious to constant erosion by natural acids, for example, acetic and formic acid.
Super Duplex Forged Threaded Fittings are utilized as a part of Oil and gas industry parts, heat exchangers, offshore platforms, service and process water systems, balance water and inection systems, fire-fighting systems, vessels, piping and Chemical process industries. Super Duplex Forged Fittings are formed from a roughly 50/50 blend of austenitic and ferritic stages and are sometimes alluded to as austenitic-ferritic stainless steels. In addition, a group of our quality controllers directs a progression of quality tests on the whole scope of Super Duplex Forged Socket Weld Fittings to search out any conceivable imperfection. Tuned in to global standard, we give the whole scope of UNS S32750 Super Duplex Forged Threaded Fittings in different tweaked choices and industry leading costs. As they withstand abrasion and chemical attack, our ASME A182 Super Duplex Steel S32760 Screwed/Threaded Fittings are equally open to weldability and workability, with we being an exporter of these quality fittings assure you guaranteed performance and safety. Also We offer wide range of Super Duplex Steel ASTM A182 Forged Fittings such as Super Duplex Steel 2507 Forged Elbow, Super Duplex S32750 Equal Tee, Super Duplex Steel S32760 Coupling, 2507 Super Duplex Steel Pipe Cap, Super Duplex Steel S32750 Union, Super Duplex Steel 2507 Bushing, Super Duplex Steel 2507 Plug, S32750 Super Duplex Steel Pipe Nipple, Super Duplex S32760 Street Elbow.
Specifications : ASTM A182 & ASME SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : S32750 / S32760 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Threaded and Socket Weld Pipe Fittings
Products | Size | |
ASTM A182 Super Duplex Steel 90° Elbows | ASTM A182 Super Duplex Steel 45° Elbows | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
ASTM A182 Super Duplex Steel Forged Caps | ASTM A182 Super Duplex Steel Couplings | |
ASTM A182 Super Duplex Steel Forged Tees | ASTM A182 Super Duplex Steel Unions | |
ASTM A182 Super Duplex Steel Forged Cross | ASTM A182 Super Duplex Steel Inserts | |
ASTM A182 Super Duplex Steel Forged Plug | ASTM A182 Super Duplex Steel Street Elbows | |
ASTM A182 Super Duplex Steel Bushings | ASTM A182 Super Duplex Steel Pipe Nipple |
Super Duplex Steel Forged Fittings Manufacturing Standards :
ASTM A182 - ASME SA182 | Standard Specification for Wrought Austenitic Super Duplex Steel Piping Fittings |
ASME B16.11 | Socket Welding and Threaded Forged Fittings |
MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
MSS SP-95 | Swage(d) Nipples and Bull Plugs |
BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
STANDARD | WERKSTOFF NR. | UNS |
Super Duplex 2507 | 1.4410 | S32750 / S32760 |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
S32750 / S32760 | 7.8 | 0.281 | 1350 | 2460 |
Super Duplex Steel Forged Pipe Fittings | Super Duplex Steel High Pressure Forged Fittings |
Super Duplex Steel 2507 Socket Weld Fittings | Super Duplex Steel S32750 Threaded Fittings |
Super Duplex Steel UNS S32760 Socket Weld 90 Deg Elbow | Super Duplex Steel F51 Threaded 90 Deg Elbow |
Super Duplex Steel Socket Weld 45 Degree Elbow Suppliers | ANSI 2507 Super Duplex Steel Screwed 45 Degree Elbow |
Super Duplex Steel Gr. F52 Forged Tee Dealer | Super Duplex Steel F53 Threaded Tee Exporter |
Super Duplex Steel S32750 Socket Weld Cross Stockholder | UNS S32760 Threaded / Screwed Cross Distributors |
Super Duplex Steel UNS S32750 Socket Weld Half Coupling | Super Duplex Steel Threaded Half Coupling Manufacturer |
Super Duplex Steel DIN 1.4410 Full Coupling | Super Duplex Steel 2507 Coupling |
Super Duplex Steel Socket Weld Cap | Ferritic / Austenitic Super Duplex Steel Screwed Cap |
ANSI B16.11 Super Duplex Steel Socket Weld Union | Super Duplex Steel 2507 Threaded / Screwed Union Stockist |
ASTM A182 Super Duplex Steel 2507 Screwed Hex Plug | ASME SA182 Super Duplex Steel Square Plug |
Super Duplex Steel F55 Reducing Tee | 2570 Super Duplex Threaded / Screwed Bushing |
A182 Super Duplex Steel F57 Hex Nipples | ASME SA182M Super Duplex Steel Swage Nipple |
2507 Super Duplex Threaded Street Elbow | Super Duplex Steel Threaded / Screwed Pipe Nipple |
Super Duplex Steel F60 Socket weld Unequal Tee | Super Duplex Steel ASME B16.11 Threaded Unequal Tee |
ASTM A182 Super Duplex Forged Fittings are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A182 Super Duplex Steel Forged Pipe Fittings through a worldwide network of stock-keeping branches. These ASTM A182 Super Duplex Steel Forged Fittings is use in various industries like :
A Wide Range Of the Best Quality Super Duplex Steel Forged Fittings, super duplex forged fittings price list, 2507 super duplex forged fittings price, asme b16.11 fittings, super duplex socket weld fittings dimensions pdf, threaded pipe fitting dimensions, socket weld pipe fittings dimensions, forged fittings definition, 3000 lb super duplex steel forged fittings, forged fittings definition, forged steel fittings, forging process, hot forging process, drop forging process, 2507 super duplex class 3000 fittings pressure rating, 150# super duplex steel socket weld fittings, b16.11 pressure rating, ansi 3000 pressure rating, class 9000 fittings pressure rating, class 300 fittings pressure rating, f51 super duplex class 3000 pipe fittings pressure rating, asme b16.11 class 3000, class 6000 fittings, super duplex steel f55 pipe coupling dimensions, steel pipe fitting dimensions chart, galvanized pipe fittings dimensions, super duplex steel 2507 socket weld fittings Manufacturer, Supplier in India.
