Alloy Steel Lap Joint Flange Jis 16k slide directly over the pipe and are usually used in combination with stub end fittings. A pipe is welded to the Stub End fitting, while the Alloy Steel Lap Joint Flange JIS 5k is free to rotate around the stub end. The benefit of the Alloy Steel Lap Joint Flange JIS 10k is that there will not be any issues with regard to the bolt hole alignment. Although Lap Joint Flange Awwa C207 Class D has all the common dimensions similar to any other flange, the Lap Joint Flange Class 600, however, does not have a raised face, as used in conjunction with a Lap Joint Stub End. Alloy Steel Lap Joint Flange Din En 1092-1 is nearly identical to a Slip-On flange with the exception of the presence of a radius at the intersection of the flange face and the bore, which accommodates the flanged portion of the Stub End.
The Alloy Steel Lap Joint Flange in India Asme B16.5 Class 300 could be used in all pressures rating environments. Loose flange is available in a full-size range. Since the Alloy Steel Lap Joint Flange India tends to slip over the pipe, they are not welded or otherwise fastened to it. Bolting pressure is transmitted to the gasket from the pressure received by the Alloy Steel Lap Joint Flange against the back of the pipe lap or Stub End.
Since, the Pn16 Lap Joint Flange are made from alloy grade stainless, they tend to have excellent mechanical properties like high tensile strength, good toughness, good hardness as well as good resistance to corrosion.
Api 6A Alloy Steel Lap Joint Flange have freedom to swivel around the pipe, which in turn facilitates the lining up of opposing flange bolt holes.
Less contact or Lack of contact with the fluid in the pipe often permits the use of inexpensive carbon based Alloy Steel Lap Joint Flange ansi b16. 5 in combination with a corrosion resistant pipe.
In systems where erosion or corrosion takes place rapidly, the Alloy Steel Lap Joint Flange 150 lbs may be salvaged for re-use.
Because Alloy Steel Lap Joint Flange Raised Face are often used for applications that require frequent dismantling or assembling, Stainless Steel Alloy Steel Lap Joint Flange Manufacturer consider them to be one of the most economical yet, durable
Alloy Steel Lap Joint Flanges are similar to other types of industrial Flanges, but it does not have a raised face. Alloy Steel Lap Joint Flanges are used in conjunction with a “Alloy Steel Lap Joint Stub End”. The total initial cost of a Alloy Steel Lap Joint Flanges along with a stub end is around one-third higher than that of comparable welding neck Flanges. The pressure holding capacity of Alloy Steel Lap Joint Flanges is comparatively lower, and the fatigue life for the assembly is only one-tenth that of welding neck Flanges. These Flanges are offered at custom-made sizes and shapes to our valued patrons.
The Alloy Steel Lap Joint Flanges with the stub end assembly is normally used in piping systems that require regular dismantling for inspection and cleaning. These Flanges slip over the pipe and are not welded or otherwise fastened to it. Bolting pressure is transmitted to the gasket by the pressure of the Flanges against the back of the pipe lap (Stub End).
We offer Alloy Steel Lap Joint Flanges manufactured at our facility to companies in various industries including shipbuilding, power generation, petrochemical plants, oil refineries, wastewater treatment plants, paper mills, pharmaceutical plants, and turnkey projects among others. We export Alloy Steel Lap Joint Flanges to Qatar, Kingdom Of Bahrain, Saudi Arabia, Indonesia, United States, Singapore, Malaysia, Turkey, UAE, Russia, Ukraine, South Africa, Australia, etc.
Standard : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Size : 1/2" (15 NB) to 48" (1200NB)
Class : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.
Flanges Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
BS : BS4504 , BS4504, BS1560, BS10
DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
Alloy Steel Alloy Steel Lap Joint Flanges : ASTM / ASME A/SA 105 ASTM / ASME A 350 , ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F70
