Fitwel Industries LLP is giving its full contribution in producing and supplying high-end quality Stainless Steel 321/321H Flanges. To manufacture the product of high quality, they use premium quality raw material and the latest technology and machinery is made. Also, various effective product production technique and strategy is taken into consideration complying with raw material standard quality. The high quality in fabrication is preventing it from getting corrode, rust, keep it free from stress corrosion cracking, pitting, and oxidation. The product is supplied at easy to affordable rates.
Grades SS A182 f321 flanges is a basic austenitic grade 18/8 steel that has been stabilized by the addition of Titanium (321). Grade 321 stainless steel is similar to 304 in terms of its chemical composition, with the only difference being in the addition of titanium. This ASTM a182 f321 grades are used as they are not sensitive to intergranular corrosion after being heated in the carbide precipitation range of 425 °C - 850 °C. The ASTM a182 f321 is the ideal grade of choice for applications that involve being used at an elevated temperature range of up to about 900 °C. Besides being able to withstand high temperatures, the stainless steel 321 flanges have high tensile strength. They also offer good resistance to scaling as well as phase stability with resistance in subsequent aqueous corrosion. Grade 321H stainless steel is a modification of the 321 stainless steel flanges reducing with a higher carbon content as compared to the former. This modification on the 321 stainless steel flanges suppliers has been done to provide improved high-temperature strength. A limitation faced by the 321 ss flanges is that titanium does not transfer well across a high-temperature arc. Hence, it is not recommended to be used as a welding consumable. The most commonly used 321 stainless steel flanges dimensions are the ASME/ANSI B16.5. The pressure for 321 stainless steel flanges ratings ranges between 150lb to 2500lb. The 321 stainless steel flanges manufacturers in India, supply these 321 stainless steel flanges to a variety of industries such as Petroleum, Chemical, Power, Construction, Gas, Metallurgy, and Shipbuilding
Specifications : ASTM A182 / A240 & ASME SA182 / SA240
Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size : 1/2" (15 NB) to 48" (1200NB)
Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Forged and Plate Flanges
Products | Size | |
ASTM A182 SS 321 Slip-On Flanges | ASTM A182 SS 321H Threaded Flanges | Sizes 1/8″ – 36″ Raised Face or Flat Face |
ASTM A182 SS 321H Weld Neck Flanges | ASTM A182 SS 321 Socket Weld Flanges | |
ASTM A182 SS 321 Blind Flanges | ASTM A182 SS 321H Reducing Flanges | |
ASTM A182 SS 321H Lap Joint Flanges | ASTM A182 SS 321 Plate Flanges | |
ASTM A182 SS 321H Orifice Flanges | ASTM A182 SS 321 Forged Flanges | |
ASTM A182 SS 321 Ring Type Joint Flanges | ASTM A182 SS 321H Square Flanges |
SS 321 / 321H Flange Standards / Types And Pressure Class :
ASME/ANSI B 16.5 | Welding Neck Flange, Slip on Flange, Blind Flange, High Hub Blind Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Ring Type Joint Flange |
PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
ASME/ANSI B 16.47 | Welding Neck Flange, Blind Flange [Series A & B] |
PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
ASME/ANSI B 16.36 | Welding Neck Flange, Slip on Flange, Threaded Flange |
PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
BS 4504 SEC 3.1 | Welding Neck Flange, Hubbed Slip on Flange, Hubbed Threaded Flange, Lapped Pipe End Flange, Plate Flange, Loose Plate Flange, Loose Plate With Weld Neck Flange, Blank Flange |
PRESSURE CLASS | PN 2.5 TO PN 40 |
BS 4504[PART 1] | Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange |
PRESSURE CLASS | PN 2.5 TO PN 400 |
BS 1560 BOSS | Welding Neck Flange, Socket Welding Flange, Slip-On Flange, Blind Flange, Screwed Boss Flange, Lapped Flange |
PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
BS10 | Welding Neck Flange, Plate Slip-On Flange, Screwed Boss Flange, Slip-On Boss Flange, Blind Flange |
TABLE | D, E, F, H |
DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
PRESSURE CLASS | PN 6 TO PN 100 |
STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
SS 321H | 1.4878 | S32109 | SUS 321H | X12CrNiTi18-9 |
Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 0.10 max | 9.00 - 12.00 | 5(C+N) – 0.70 max |
SS 321H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Stainless Steel 321 Flanges | Stainless Steel 321H EN 1092-1 Flanges |
Stainless Steel 321 BS 4504 Flanges | Stainless Steel 321H Forged Flanges |
Stainless Steel UNS S32100 Flanges | Stainless Steel 321 Slip on Flanges |
SS 321H Flat Flange Suppliers | ANSI 321 Stainless Steel Blind Flange |
SS UNS S32109 Weld Neck Flanges Dealer | SS 321 Socket weld Flanges Exporter |
SS 321H Long Weld Neck Flanges Stockholder | Steel 321 Threaded Flanges Distributors |
Stainless Steel SUS 321 Reducing Flanges | SS 321H Ring Type Joint Flanges Manufacturer |
Stainless Steel DIN 1.4547 Orifice Flange | Stainless Steel DIN 1.4878 Spectacle Blind Flanges |
Stainless Steel 321 WNRF Flange | Stainless 321H SORF Flanges |
ANSI B16.5 SS 321H RTJ Flanges | SS 321 Screwed Flanges Stockist |
ASTM A182 SS 321H Lap Joint Flanges | ASME SA182 SS 321 BLRF Flange |
Stainless Steel 321 Raised Face Flanges | 321H SS Nipoflange |
A182 SS 321H Square Flanges | ASME SA182M SS 321 SWRF Flange |
Steel 321 Tongue & Groove Flanges | SS 321H Male & Female Flanges |
Stainless Steel 321 DIN Flanges | SS 321H ASME B16.5 Flanges |
ASTM A182 321 / 321H Pipe Flanges are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A182 321 / 321H Stainless Steel Flanges through a worldwide network of stock-keeping branches. These ASTM A182 321 / 321H Flange is use in various industries like :
